Factory custom dove prism

High-precision Dove prism achieves double-angle image rotation, unchanged beam path, low distortion & high transmittance.

Ideal optical element for astronomical instruments, laser alignment, telescopic imaging and precision optical image adjustment systems.

Typical Parameters

1. Material: BK7 optical glass, fused silica
2. Working wavelength: 400nm – 1100nm
3. Surface quality: 60/40, 40/20
4. Flatness: λ/4 @632.8nm
5. Coating: AR anti-reflection coating
6. Light deflection angle: 0°, beam direction unchanged
7. Image rotation: θ prism rotation = 2θ image rotation
8. Clear aperture, size & length can be customized
9. Low wavefront distortion, low stray light

Applications

Astronomical telescopes, image rotation systems, binocular optical systems, laser beam adjustment, optical interferometers, precision measuring instruments, panoramic im
